出口菲律宾酒店污水处理设备项目
编辑：出口污水处理设备 来自：https://www.zqwscl.com / 日期：2022-10-24 13:15 / 人气：
本项目是出口菲律宾酒店污水处理设备项目，处理水量为30吨，中侨启迪根据调研，为其设计的工艺为AO+MBR的组合工艺，该工艺能达到污水处理标准的一级A标准。
工艺原理：
1、AO工艺
AO是Anoxic Oxic的缩写，它的优越性是除了使有机污染物得到降解之外，还具有一定的脱氮除磷功能，是将厌氧水解技术用为活性污泥的前处理，所以AO法是改进的活性污泥法。
AO工艺将前段缺氧段和后段好氧段串联在一起，A段DO不大于0.2mg/L，O段DO=2～4mg/L。在缺氧段异养菌将污水中的淀粉、纤维、碳水化合物等悬浮污染物和可溶性有机物水解为有机酸，使大分子有机物分解为小分子有机物，不溶性的有机物转化成可溶性有机物，当这些经缺氧水解的产物进入好氧池进行好氧处理时，提高污水的可生化性，提高氧的效率；在缺氧段异养菌将蛋白质、脂肪等污染物进行氨化（有机链上的N或氨基酸中的氨基）游离出氨（NH3、NH4+），在充足供氧条件下，自养菌的硝化作用将NH3-N（NH4+）氧化为HO3-，通过回流控制返回至A池，在缺氧条件下，异氧菌的反硝化作用将NO3-还原为分子态氮（N2）完成C、N、O在生态中的循环，实现污水无害化处理。
2、MBR工艺
在污水处理，水资源再利用领域，MBR又称膜生物反应器（Membrane Bio-Reactor），是一种由活性污泥法与膜分离技术相结合的新型水处理技术。
MBR 工艺通过将分离工程中的膜分离技术与传统废水生物处理技术有机结合，不仅省去了二沉池的建设，而且大大提高了固液分离效率，并且由于曝气池中活性污泥浓度的增大和污泥中特效菌（ 特别是优势菌群 ） 的出现，提高了生化反应速率。同时，通过降低 F/M 比减少剩余污泥产生量（甚至为零），从而基本解决了传统活性污泥法存在的许多突出问题。
出口菲律宾酒店污水处理设备的特点：
1、紧凑，体积小，占地面积小，可地埋式结构，可移动，便于绿化且无蚊蝇滋生。
2、有机污染物去除率高，出水水质稳定。
3、操作简单，施工方便，无需特殊维护，设备自我保护性好。
4、处理水质好，达到排放标准要求。
5、一体化设备可根据原水水质进行灵活配置，使该设备具有广泛的适用性。
6、MBR最重要的部分是它的控制原理，抽吸泵由液位控制，并且间歇运行，中空纤维帘式膜还需要与清水反洗和药洗联动控制，中侨启迪已充分掌握其控制原理，使膜的寿命最大化。
控制系统：
本项目使用的是中侨启迪根据行业特性量身定做的专业的污水处理云平台，与同行业的控制系统相比，具有以下独特的功能：
1、可以更换项目LOGO和图标。
2、设备台账、报修、安装管理功能。
3、除电脑端、手机APP端还支持微信小程序登录。
4、离线记录数据可查询。
5、用户手机端及电脑端支持大屏预览。
售后服务：
“专一专业专于环保，专心专注专于污水”，中侨启迪对待每一个项目都深入详尽，以周到的服务，赢得广大客户的信任与厚爱。以服务为基础，以质量为生存，以科技求发展，坚持诚信服务的原则。
以上就是中侨启迪出口菲律宾酒店污水处理设备项目的基本资料了。如果您也想定制污水处理设备，可以直接联系中侨启迪的客服或者到公司参观交流，期待与您合作。
Project overview：
This project is a sewage treatment equipment project for hotels exported to the Philippines, with a treatment capacity of 30 tons. According to the investigation, the process designed by Zhongqiao Qidi is the combination process of AO+MBR, which can reach the first-class A standard of sewage treatment standard.
Process principle：
1. AO process
AO is the abbreviation of Anoxic Oxic. Its advantage is that it not only degrades organic pollutants, but also has a certain function of nitrogen and phosphorus removal. It uses anaerobic hydrolysis technology as the pretreatment of activated sludge, so AO method is an improved activated sludge method.
In the AO process, the front anoxic section and the back aerobic section are connected in series, and the DO in the A section is not more than 0.2mg/L, and the DO in the O section is 2 ~ 4 mg/L. In the anoxic stage, heterotrophic bacteria hydrolyze suspended pollutants such as starch, fiber, carbohydrate and soluble organic matters in sewage into organic acids, so that macromolecular organic matters can be decomposed into micromolecule organic matters, and insoluble organic matters can be converted into soluble organic matters. When these products after anoxic hydrolysis enter an aerobic tank for aerobic treatment, the biodegradability of sewage and oxygen efficiency can be improved. In the anoxic stage, heterotrophic bacteria ammoniate pollutants such as protein and fat (N in organic chain or amino in amino acid) to release ammonia (NH3 and NH4+). Under the condition of sufficient oxygen supply, the nitrification of autotrophic bacteria oxidizes NH3-N(NH4+) into HO3-, and returns to pool A through reflux control. Under the anoxic condition, denitrification of heterotrophic bacteria reduces NO3- to molecular nitrogen (N2) for completing the circulation of C, N and O in the ecology, and realizing the harmless treatment of sewage.
2. MBR process
In the field of sewage treatment and water resources reuse, MBR, also known as Membrane Bio-Reactor, is a new water treatment technology which combines activated sludge process with membrane separation technology.
By organically combining membrane separation technology in separation engineering with traditional wastewater biological treatment technology, MBR process not only saves the construction of secondary sedimentation tank, but also greatly improves the solid-liquid separation efficiency. Moreover, due to the increase of activated sludge concentration in aeration tank and the appearance of special bacteria (especially dominant bacteria) in sludge, the biochemical reaction rate is increased. At the same time, by reducing the F/M ratio, the excess sludge production can be reduced (even zero), thus basically solving many outstanding problems existing in the traditional activated sludge process.
Characteristics of sewage treatment equipment for export hotels in Philippines：
1. Compact, small size, small floor area, underground structure, mobility, convenience for greening and no breeding of mosquitoes and flies.
2. The removal rate of organic pollutants is high, and the effluent quality is stable.
3 . Simple operation, convenient construction, no special maintenance and good self-protection of equipment.
4. The treated water quality is good and meets the requirements of discharge standards.
5. The integrated equipment can be flexibly configured according to the quality of raw water, which makes it widely applicable.
6. The most important part of MBR is its control principle. The suction pump is controlled by liquid level and runs intermittently. The hollow fiber curtain membrane also needs linkage control with clean water back washing and drug washing. Zhongqiao Qidi has fully mastered its control principle to maximize the life of the membrane.
Control system：
This project uses a professional sewage treatment cloud platform tailored by Zhongqiao Qidi according to the characteristics of the industry. Compared with the control system of the same industry, it has the following unique functions:
1. You can change the project LOGO and icon.
2. Equipment ledger, repair service and installation management functions.
3. In addition to computer and mobile APP, WeChat applet login is also supported.
4. The offline recorded data can be queried.
5. The user's mobile phone and computer support large-screen preview.
After-sales service：
"Dedicated to environmental protection, dedicated to sewage", Zhongqiao Qidi treats every project in depth and detail, and wins the trust and love of our customers with thoughtful service. Take service as the foundation, quality as the survival, science and technology as the development, and adhere to the principle of good faith service.
The above is the basic information of the sewage treatment equipment project of Zhongqiao Qidi Hotel exported to the Philippines. If you also want to customize sewage treatment equipment, you can directly contact the customer service of Zhongqiao Qidi or visit and exchange with the company. We look forward to cooperating with you.
