山东污水处理设备出口
编辑:出口污水处理设备 来自:https://www.zqwscl.com /日期:2022-03-23 16:27 / 人气:
山东污水处理设备出口制作标准和国内为统一标准,具体如下几点:
1.箱体材质:采用优质碳钢制作箱体,利用环氧型富锌底漆做防腐处理;
2.钢板厚度:箱体钢板厚度≥8mm,箱体侧板、顶板、底板采用矩管加强筋,外壁加装受力支架;
3.外形:一体化集装箱式装置,外部侧板采用国标钢板,增加强度,以保证设备整体安装、转运等的稳定性,配置吊装标准件,内部根据工艺需求进行设计;
4.外漆颜色、喷涂标语:外表面颜色为蓝白色/灰色/绿色/黑色。标语根据业主要求进行设计和喷绘,设备外观可以根据业主要求做适当调整;
5. 防腐标准:箱体的主体部件需要进行预处理,表面喷砂、除锈、去油污处理,喷涂环氧型富锌底漆(外部采用钢结构氟碳漆防腐面漆)一遍,箱体内底漆二遍、中间环节二遍、面漆一遍,共计五遍油漆,箱体外观底漆二遍、面漆二遍,水箱内喷涂环氧煤沥青底漆、面漆, 外壁喷涂集装箱专用底漆、面漆、丙烯酸聚氨酯油漆,容器内 壁(除设备间)及需要做防腐的管路为黑色。
以上就是中侨启迪小编为您整理的关于山东污水处理设备出口相关的资料了,如果您想要购买出口污水处理设备可以联系我们的客服工作人员或者是到我们公司进行实地考察,我们十分欢迎您的到来!
At this year's 315 party, we saw how the "double standard" of a certain food industry has strict requirements on the processing of exported food, while the processing conditions of food sold in China are very "unbearable to look directly", which makes people angry. Fortunately, the production of our sewage treatment equipment is unified. The export of sewage treatment equipment in Shandong and the equipment provided to us in China are made in accordance with unified standards. The following Chinese overseas Chinese enlightenment Xiaobian will take you to know about the export of sewage treatment equipment in Shandong.
Shandong sewage treatment equipment export manufacturing standards and domestic standards are unified, as follows:
1. Box material: the box is made of high-quality carbon steel, and the epoxy zinc rich primer is used for anti-corrosion treatment;
2. Steel plate thickness: the steel plate thickness of the box body is ≥ 8mm, the side plate, top plate and bottom plate of the box body adopt rectangular tube stiffeners, and the outer wall is equipped with stress support;
3. Appearance: integrated container type device. The external side plate adopts national standard steel plate to increase the strength, so as to ensure the stability of the overall installation and transportation of the equipment. It is equipped with hoisting standard parts, and the interior is designed according to the process requirements;
4. External paint color and spraying slogan: the color of the external surface is blue white / gray / Green / black. The slogan shall be designed and painted according to the owner's requirements, and the appearance of the equipment can be adjusted appropriately according to the owner's requirements;
5. Anti corrosion standard: the main parts of the box body need to be pretreated, sandblasted, derusted and degreased on the surface, sprayed with one coat of epoxy zinc rich primer (the external steel structure fluorocarbon paint anti-corrosion finish), two coats of primer in the box body, two coats of intermediate links and one coat of finish paint, a total of five coats of paint, two coats of primer and finish paint on the appearance of the box body, epoxy coal tar primer and finish paint in the water tank, and special primer and finish paint for container on the outer wall Finish paint, acrylic polyurethane paint, vessel inner wall (except equipment room) and pipeline requiring anti-corrosion shall be black.
The above is the information about the export of sewage treatment equipment in Shandong sorted out by Zhongqiao enlightenment Xiaobian for you. If you want to buy export sewage treatment equipment, you can contact our customer service staff or go to our company for field investigation. We welcome you very much!
