烟台外贸污水处理设备
编辑：出口污水处理设备 来自：https://www.zqwscl.com /日期：2023-10-24 10:47 / 人气：
这套烟台外贸污水处理设备采用的是中侨启迪成熟的MBR膜生物反应器技术。
MBR技术是在真空泵与产水泵的抽吸作用下，利用膜装置内的中空纤维，对生化池中的悬浮混合液进行固液分离的一种污水处理技术。其主要利用了膜的选择透过性，在生化池中实现了生物的富集，从而也大大的提高了生物处理的效率。MBR技术进行污水处理中，利用膜的高效截留功能可以让泥水达到满意的分离效果，而被截留下来的污泥也会以300%～400%的回流率回流至生化缺氧池中。另外，在膜装置内也设置了曝气装置，该装置能采用气水振荡的方式对膜进行清洗，以保持膜表面的干净，还能为好氧微生物提供所需的氧气。MBR的工艺特点主要包括以下几个方面：
1）固液分离功能强，滤出水中所含的悬浮物等固体杂质较少；
2)反应器中的污泥浓度较高，而且其容积的负荷也较高，因此，减少了系统的产泥量；
3)反应器内有很多的生物种群，它们能够提高去污效果；
4)整个系统采用的是模块化设计，具有占地面积小、操作简单、易扩展等优点，且能够使全程的实现自动化控制。
烟台外贸污水处理设备的工艺流程
生活污水首先流入格栅池，在格栅池中需要用细格栅除去污水中较大颗粒的杂质，以避免其阻塞与损伤泵，减轻其负荷。存储在格栅池中的污水由提升泵提升至调节池，然后到缺氧池，再自流到MBR池中。在MBR池中设置有中空纤维膜组件，污水浸没膜组件，通过自吸泵的抽取，利用膜丝内腔的抽吸负压来运行。自吸泵中的出水是进入消毒设备中，然后对其进行杀菌消毒，最后置于回用池待用。MBR池中的多余污泥回流至缺氧池中，而缺氧池中多余的污泥则排放至污泥浓缩池，定期将其淘汰。
烟台外贸污水处理设备中的膜生物反应器工艺主要指通过生物技术与膜分离技术的有机结合进行废水处理的技术。其中膜分离设备能够使生化反应池中的大分子有机物质及活性污泥截留住，并省掉二沉池，从而使活性污泥浓度得以提高，污泥停留时间以及水力停留时间都能得到控制，而且在反应器中比较难降解的物质也会发生降解、反应。因此，相比传统生物处理方法，膜生物反应器工艺所采用的膜分离技术更能使生物反应器功能得以强化，是比较新型且利用极为广泛的废水处理新技术之一。
烟台外贸污水处理设备是由山东中侨启迪环保装备有限公司生产制造的，与传统的生物处理方法相比，具有抗负荷冲击能力强、出水水质稳定、排泥周期厂、占地面积小、生化效率高、易实现自动控制等特点。
如果您有需要外贸出口一体化污水处理设备，可以联系山东中侨启迪环保装备有限公司。
As we all know, the whole world is facing the problem of water shortage, and the problem of sewage treatment is particularly important. With the development of the domestic environmental protection industry, the domestic integrated sewage treatment equipment began to continuously export foreign trade. Let's take a look at the next set of Yantai foreign trade sewage treatment equipment process flow.
This set of Yantai foreign trade sewage treatment equipment is a mature MBR membrane bioreactor technology.
MBR technology is a sewage treatment technology that uses solid-liquid separation of the suspended mixture in the hollow fiber in the membrane device under the suction action of the vacuum pump and the production pump. It mainly makes use of the membrane selection permeability, and realizes the biological enrichment in the biochemical pool, thus greatly improving the efficiency of biological treatment. In sewage treatment by MBR technology, the efficient interception function of film can achieve the satisfactory separation effect of muddy water, and the trapped sludge will be returned to the biochemical anoxic tank at a reflux rate of 300%~400%. In addition, an aeration device is also set in the membrane device, which can clean the membrane by means of air and water oscillation to keep the membrane surface clean and provide the required oxygen for aerobic microorganisms. The process characteristics of MBR mainly include the following aspects:
1) Strong solid-liquid separation function, and less solid impurities contained in the water;
2) The sludge concentration in the reactor is high, and the load of its volume is also high, so the mud production of the system is reduced;
3) There are many biological populations in the reactor, which can improve the decontamination effect；
4) The whole system adopts the modular design, which has the advantages of small footprint, simple operation, easy expansion and so on, and can make the whole process of automatic control.
Yantai foreign trade sewage treatment equipment process flow
Domestic sewage first flows into the grid pool. In the grid pool, a fine grid is needed to remove the impurities of large particles in the sewage to avoid its obstruction and damage to the pump and reduce its load. The sewage stored in the grille tank is lifted from the lifting pump to the regulating tank, then to the hypoxia tank, and then to the MBR tank. In the MBR pool, there are hollow fiber membrane components and sewage immersion membrane components, which are operated by the self-suction pump and the suction negative pressure of the inner chamber of the membrane wire. The water in the self-priming pump is put into the disinfection equipment, and then sterilized, and finally placed in the reuse pool for use. The excess sludge in the MBR tank is returned to the oxygen-deficient tank, while the excess sludge in the oxygen-deprived tank is discharged to the sludge concentration tank, which is eliminated regularly.
The membrane bioreactor process in Yantai foreign trade sewage treatment equipment mainly refers to the wastewater treatment technology through the organic combination of biotechnology and membrane separation technology. The membrane separation equipment can make the macromolecular organic substances and activated sludge in the biochemical reaction tank intercept, and save the secondary sedimentation tank, so that the concentration of activated sludge can be improved, the sludge residence time and hydraulic residence time can be controlled, and the substances that are difficult to degrade in the reactor will also degrade and react. Therefore, compared with the traditional biological treatment method, the membrane separation technology used in the membrane bioreactor process can strengthen the function of the bioreactor, which is one of the new and widely used wastewater treatment technologies.
Yantai foreign trade sewage treatment equipment is manufactured by Shandong Zhongqi enlightenment Environmental Protection Equipment Co., LTD. Compared with the traditional biological treatment method, it has the characteristics of strong load impact resistance, stable effluent quality, mud discharge cycle plant, small area, high biochemical efficiency, easy to achieve automatic control and so on.
If you need foreign trade export integrated sewage treatment equipment, you can contact Shandong Zhongqiao Enlightenment environmental Protection Equipment Co., LTD.
