外贸集装箱污水处理设备的安装方法
编辑：出口污水处理设备 来自：https://www.zqwscl.com /日期：2022-12-12 11:36 / 人气：
1.根据安装图纸和基本图纸，根据安装方案的大小准备基础，并制作混凝土地面。基本要求为5t / m2，基础必须水平，并应在混凝土基础浇筑维护期结束后安装。如果设备安装在地板下方，则地基与地面的相对高度应基于地图的大小。同时，周围开挖的宽度应距离管道安装基线500mm以上。
2.设备安装到位时，应考虑管道的安装和连接。当设备到位时，必须根据设备的手动重量。根据起重机的吨位，根据现场对比图表安装顺序。气缸的位置和方向不能错位，一定是对的。
3.根据安装图，连接管道。设备安装到位后，连接管用橡胶垫固定，使接头不会泄漏。
4.安装后，必须连接并固定设备和基础地板。绝对保证不让设备上下流动。同时，必须将污水注入设备（当没有污水时，用其他水源或自来水替换），充满度必须达到70％以上。防止设备浮动。同时，检查管道是否有泄漏。试验水的管道不得泄漏，设备不受地下水上升的影响，导致设备错位和倾斜。
5.设备安装完成后，可以用土填充缝隙周围的设备并夯实，填充地面填料时，应注意：
（1）设备的井盖必须是在地板上方约50mm处；
（2）不要让土壤堵塞井盖上的进气口。
6.将电控柜的控制面板连接到设备。接线时，请注意风扇和潜水泵电机的转向。控制柜应放在通风的地方，以保持干燥。一般控制柜不应放在户外。避免日晒，雨淋等。为避免控制板和接线头泄漏，请将控制板烧坏。
7.注意事项：
（1）设备的安装必须确保雨中没有水，
（2）设备顶部不应有重物，没有大型车辆通过（参照否特殊设计），
（3）不允许使用设备。抽取内部污水以防止地下水漂浮。
8.根据标准连接和平面布局，注意设备的安装图和管道连接图。如果用户要求可以任意安排，则必须在合同签订时提交。
9.连接风扇和水泵控制线，并注意风扇，水泵和抽吸泵的正确转向。
中侨启迪位于山东省潍坊市，这里是世界风筝都、国际动力城，中侨启迪匠心工艺，生产高端污水处理设备。如果您想外贸集装箱污水处理设备，可以联系中侨启迪的客服或者到公司参观交流。
Today, xiaobian will give you the popularization of container sewage treatment equipment installation methods and matters needing attention.
1. Prepare the foundation according to the installation drawings and basic drawings, and the size of the installation scheme, and make the concrete floor. The basic requirement is 5t / m2, the foundation must be horizontal and installed after the maintenance period of concrete foundation. If the equipment is installed below the floor, the relative height of the foundation to the ground shall be based on the size of the map. At the same time, the width of the surrounding excavation should be more than 500mm away from the pipeline installation baseline.
2. When the equipment is installed in place, the installation and connection of the pipeline shall be considered. When the equipment is in place, it must follow the manual weight of the device. According to the tonnage of the crane, the installation sequence. The position and direction of the cylinder can not be misplaced, it must be right.
3. Connect the pipe according to the installation drawing. After the equipment is installed in place, the connection pipe is fixed with rubber pads so that the joint will not leak.
4. After the installation, the equipment and the foundation floor must be connected and fixed. Absolutely prevent the equipment from flowing up and down. At the same time, the sewage must be injected into the equipment (when there is no sewage, replaced with other water sources or tap water), and the fullness must be more than 70%. Prevent the device from floating. Also, check the pipe for leaks. The pipe of the test water shall not leak, and the equipment shall not be affected by the groundwater rise, resulting in the dislocation and inclination of the equipment.
5. After the installation of the equipment, the equipment around the gap can be filled with soil and compacted. When filling the ground packing, attention should be paid attention to:
(1) The manhole cover of the equipment must be about 50mm above the floor;
(2) Do not let the soil plug up the air inlet on the manhole cover.
6. Connect the control panel of the electric control cabinet to the equipment. When wiring, please pay attention to the steering of the fan and the submersible pump motor. The control cabinet shall be placed in a ventilated place to keep it dry. The general control cabinet should not be placed outdoors. Avoid the sun, rain, etc. To avoid leakage of the control board and wiring head, burn the control board.
7. Notes:
(1) The installation of the equipment must ensure that there is no water in the rain,
(2) There shall be no heavy objects on the top of the equipment, and no large vehicles shall pass through (refer to no special design),
(3) The use of the equipment is not allowed. Draw internal sewage to prevent groundwater from floating.
8. According to the standard connection and plane layout, pay attention to the equipment installation diagram and pipe connection diagram. If the user requests any arrangement, it must be submitted at the time of contract.
9. Connect the fan and the pump control line, and pay attention to the correct steering of the fan, pump and suction pump.
It is located in Weifang city, Shandong Province, which is the world kite capital and the international power city. It has great craftsmanship and produces high-end sewage treatment equipment. If you want foreign trade container sewage treatment equipment, you can contact the customer service of Chinese enlightenment or visit the company for communication.
